Secretive Long Range Attack Missile For Marine AH-1s Is Now Being Flight Tested

The Long Range Attack Missile, based on an unknown Air Force weapon, will help ensure Marine AH-1Zs stay relevant in future high-end fights.
www.twz.com www.twz.com

Specific details about the LRAM's capabilities are limited, but the Marine Crops has said in the past that it will have a maximum range of at least 150 nautical miles (just over 170 miles or nearly 278 kilometers) and will be capable of engaging moving land and sea targets.
Click to expand...

Some interesting information on HALO (I think). Some interesting information on HALO (I think). 3,000m/s @ 25km altitude, that be Mach 10 (a little over Mach 1 = 298m/s at that altitude), 1,700m/s at S/L, that's Mach 5 at impact, ouch.

https://twitter.com/x/status/1789668290979082632


Last edited:
randomradio said:
Star navigation of the yesteryears.
Click to expand...
Nope, far more accurate internal systems. This was recently brought up on secret projects, commercial RLGs can provide the same or better accuracy than GPS for munitions like GMLRS and GL-SDB now, the use of GPS is just a legacy of the era they were fielded in.

  • Like
Reactions: suryakiran
BMD said:
Nope, far more accurate internal systems. This was recently brought up on secret projects, commercial RLGs can provide the same or better accuracy than GPS for munitions like GMLRS and GL-SDB now, the use of GPS is just a legacy of the era they were fielded in.
Click to expand...

The idea is RLGs and FOGs provide inertial navigation, and any drift is corrected by an external reference system like GPS.

But if GPS fails, a third backup is required, and that's typically astrometry.

Even GPS satellites are caliberated with lunar data.

randomradio said:
The idea is RLGs and FOGs provide inertial navigation, and any drift is corrected by an external reference system like GPS.

But if GPS fails, a third backup is required, and that's typically astrometry.

Even GPS satellites are caliberated with lunar data.
Click to expand...
Nope. The RLGs themselves can deliver accuracy of 0.0035deg/hour, which over a 150km, <10 minute flight for GLSDB works out to <1.5m error and probably less than half that for GMLRS. It's probably be even cheaper than GPS too, and unjammable.

tan (0.0035deg/hr) x 150,000m x (10/60)hrs = 1.5m

A 2S7 is 10.5m long and 3.4m wide, 1.5m off centre is still a direct hit.


And that's just a crappy $1000 commercial system. Even more accurate systems were produced even 40 years ago, they were just prohibitively expensive back then.

en.wikipedia.org

Advanced Inertial Reference Sphere - Wikipedia

en.wikipedia.org en.wikipedia.org
drift less than 1.5×10−5 °/h
Click to expand...
^That equates to only 1.8m over a 14,000km, 30 minute flight!

These days, within the budget of a hypersonic missile, you could likely spec. a system with similar accuracy for $100k.

Last edited:
